This series of power supplies can generate output that ranges from 1kV to 150kV, 50W to 1kW and are housed in compact 19” racks to give a highly regulated output.
| PARAMETER | SPECIFICATION | |
|---|---|---|
| Input Voltage | 230V ±10% A C, 50Hz, single phase | |
| Output Voltage Range* | 1kV DC to 150kV DC | |
| Output Power Range* | 50W to 1kW | |
| Polarity | Positive / Negative | |
| Line Regulation | ≤0.5% for 10% variation in input voltage | |
| Load Regulation | ≤1% for 0 to 100% load variation | |
| Ripple | ≤0.1% rms at full rating | |
| Stability | Better than 0.05%/hour after 1 hour warm-up | |
| Regulation Mode* | Constant Voltage – Constant Current | |
| Voltage & Current Control* | Local: By 10-turn potentiometers on the front panel Remote: 0 to 10V DC signals for voltage & current control; OR Control through computer interface | |
| Protections* | Against over load, over current, over voltage, short-circuit and arc | |
| Remote Controls & Signals through pluggable Connector / D-Connector (External RS232 Microcontroller Module)* | 10V DC reference 10V DC HV enable signal 0 to 10V DC signal for voltage & current control 0 to 10V DC signal for voltage & current monitoring | |
| Front Panel | AC power ON/OFF switch with indication HV ON/OFF switch with indication 3½ digit voltage and current meters 10-turn potentiometers for voltage and current control Constant voltage – constant current mode indication | |
| Back Panel |
| |
| Topology | High frequency resonant / PWM-controlled switch mode | |
| Switching Device | IGBT | |
| Cabinet | 2U/3U, 19″ rack, powder coated |
